Ichthys Project Gas Export Pipeline (Operation)

Activity type Operation of a petroleum pipeline
Activity subtypes
Submitted by Ichthys LNG Pty Ltd
Submission date 20 September, 2016
Subtype New
Decision date 11 January, 2017
RMS ID 3690
Status Finalised
Outcome Accepted
Link to previously accepted EP
Contact

Sandy Griffin
INPEX Operations Australia Pty Ltd
100 St Georges Terrace
PERTH WA 6000
Tel: +61 8 6213 6860
sandy.griffin@inpex.com.au

Location map (click to enlarge)
Location map - Activity: Ichthys Project Gas Export Pipeline (Operation) (refer to description)
Description


Operation of the GEP involves the transportation of GEP gas through the GEP to the Ichthys LNG Plant in Darwin.
Inspections provide assurance that infrastructure is performing according to design. They also proactively identify maintenance and/or repair activities that may be required to protect the GEP integrity.
Inspection activities within the EP include:
remotely operated underwater vehicle (ROV) or autonomous underwater vehicle (AUV) inspections
marine acoustic surveys.
Maintenance and repair activities described in this EP are not intended to occur but, if required, may include:
seabed intervention (e.g. jetting, mass flow excavation, installing grout bags, rock placement or concrete mattress installation)
marine growth removal
pigging to recover the integrity of, or isolate, the GEP in the event of a repair
clamp repairs
major repairs, including use of a pipeline repair system (PRS) used to replace sections of pipe.

Activity Location
The GEP is approximately 889 km long, with approximately 793 km of it located within Commonwealth waters, between the Ichthys Field and the Northern Territory (NT) three-nautical-mile (nm) limit (Figure 1-1). Activities covered by this EP are wholly located in Commonwealth waters and the operational area is defined as a two-kilometre-wide corridor, 1 km either side of the GEP centreline, up to the GERB.
The water depths range from ~250 m below lowest astronomical tide (LAT) at the GERB, to ~30 m LAT, at the boundary of Commonwealth waters and the NT three-nautical-mile limit.

This information has been extracted from the environment plan submitted.

Other Details
Locations North West
Commonwealth waters adjacent to Northern Territory , Western Australia
Titles (or other instruments) NT/PL4
WA-22-PL
